Bi-Directional Data Transfer Architecture

Bi-directional data transfer architecture diagram

bi-directional-data-tarnsfer

Proposed Architecture for the Implementation of bi-directional data Transfer

CRM Service:

CRM will have an endpoint for webhooks from different external systems to notify the change in their system. https://crm-3tmvxtxoxq-ez.a.run.app/tenants/{tenantId}/adapters/{adapterId}/events

CRM will authorize the tenant.
will get the adapter type from the configuration and attach it to the event as an attribute and push it to the pub/sub.
publishes the message to the respective adapter based on the attribute in the message body.

Adapter Services:

respective adapter creates the event based on the entity type, and action type, adds context, and pushes the event to Google task.
Google task will deliver the events to the event handler in configuration.

Event Handler Service (Configuration):

gets which internal products are interested in the particular event and the action from the database.
creates a message for each product that is interested and attaches the attribute of the product type to the message.
pushes the messages to the pub/sub (or event arc)
pub/sub delivers the message to the internal product based on the attribute attached to the message.

Internal Products:

Internal products will consume the event at their phase and priority from the queue.
